产品分类

热界面材料

继续细分

按产品类型选择

10下级分类

PRODUCT SERIES

热界面材料产品系列

包含当前分类及其下级分类中的系列,同一系列合并展示。

148 个系列
CoolTherm® EP-6007 BLK/6252 Epoxy System

CoolTherm® EP-6007 BLK/6252 Epoxy System

CoolTherm® EP-6007 BLK/6252 epoxy system is used as a thermally conductive, thin bondline adhesive for attaching semiconductors to heat sinks, and as a potting/casting product when thermal conductivity & non-burning properties are required.

颜色Black Liquid (resin), Amber Liquid (hardener) 动态粘度15000 cP @ 25°C (resin), 75 cP @ 25°C (hardener) 比重1.69 (resin), 0.99 (hardener)
CoolTherm® SC-3500 导热硅胶填缝剂

CoolTherm® SC-3500 导热硅胶填缝剂

CoolTherm® SC-3500 导热、低挥发性有机硅填隙剂是一种双组分系统,旨在为电子应用提供出色的导热性,同时保留与有机硅相关的理想性能。

颜色Off-White Paste (resin), Pink Paste (hardener), Light Pink Paste (mixed) Number of ComponentsTwo-Component (2K) 动态粘度114000 cP @ 25°C (resin), 80000 cP @ 25°C (hardener)
CoolTherm® TC-404 Thermally Conductive Grease

CoolTherm® TC-404 Thermally Conductive Grease

CoolTherm® TC-404 thermally conductive grease is a non-reactive, solvent-free silicone material designed for applications where a highly conductive thermal interface material is required and where the device may later need to be easily removed.

颜色Gray Paste Number of ComponentsOne-Component (1K) 动态粘度212400 cP @ 25°C, Shear Rate 5/sec, 141800 cP @ 25°C, Shear Rate 10/sec
CoolTherm® UR-2000 Thermally Conductive Urethane Gap Filler

CoolTherm® UR-2000 Thermally Conductive Urethane Gap Filler

CoolTherm® UR-2000 gap filler is a two-component thermally conductive urethane system designed to provide thermal conductivity for electronic applications. It cures at room temperature to produce a flame-retardant adhesive.

颜色Red to Pink Paste (resin), White Paste (hardener), Pink Paste (mixed) Number of ComponentsTwo-Component (2K) 动态粘度745000 cP @ 25°C, 1/sec Shear Rate (resin), 780000 cP @ 25°C, 1/sec Shear Rate (hardener), 400000 cP @ 25°C, 1/sec Shear Rate (mixed)
CoolTherm® SC-1600 Thermally Conductive Silicone Gap Filler

CoolTherm® SC-1600 Thermally Conductive Silicone Gap Filler

CoolTherm® SC-1600 thermally conductive silicone gap filler is a two-component system designed to provide thermal conductivity for electronic applications, while retaining desirable properties associated with silicones.

颜色Pink Paste (resin), Off-White to Gray Paste (hardener), Light Pink Paste (mixed) Number of ComponentsTwo-Component (2K) 动态粘度114000 cP @ 25°C (resin), 75000 cP @ 25°C (hardener)
CoolTherm® SC-3000 LD Thermally Conductive Silicone Gap Filler

CoolTherm® SC-3000 LD Thermally Conductive Silicone Gap Filler

CoolTherm® SC-3000 LD (Low Density) gap filler is a low density, two-component silicone system designed to provide excellent thermal conductivity for electronic applications, while retaining desirable properties associated with silicones.

颜色Off-White Paste (resin), Pink Paste (hardener), Light Pink Paste (mixed) Number of ComponentsTwo-Component (2K) 动态粘度110000 cP @ 25°C (resin), 90000 cP @ 25°C (hardener)
CoolTherm® SC-2000 SLW Thermally Conductive Silicone Gap Filler

CoolTherm® SC-2000 SLW Thermally Conductive Silicone Gap Filler

CoolTherm® SC-2000 SLW (slow) thermally conductive, soft-curing gap filler is a two-component system which provides excellent thermal conductivity for electronic applications, while retaining desirable properties associated with silicones.

颜色White Paste (resin), Pink Paste (hardener), Light Pink Paste (mixed) Number of ComponentsTwo-Component (2K) 动态粘度50000 cP @ 25°C (resin), 40000 cP @ 25°C (hardener), 45000 cP @ 25°C (mixed)
